shenzhen guangzhi technology co., ltd.
Professional, innovative, cooperative, mutual trust
Add to Cart
| PARAMETERS | |
| Defend Grade | IP65 |
| Keys | 68 keys |
| Vandal resistant | IK09 |
| Electrical lifetime | > 5 years |
| Contact resistance | 200 ohm (max) |
| Current Rating | appr. 30mA |
| Power supply | + 5V +/- 5% |
| Led color | option |
| G.W. | 1kg approx |
| Frame/keys materials | Stainless steel |
| life span | ≥2 million |
| Elasticity of key | 2.5-3N |
| Key travel | ≤100Ω |
| Atmospheric pressure | 60-106Kpa |
| Operate Temperature | -40℃~+85℃ |
| Travel distance | 0.45mm |
Material
Face plate: 304 stainless steel
Keys: 304 stainless steel
Back plate: SUS304
Special feature:
Full travel keys, excellent typing feel;
Specially designed to operate in harsh environments, making them ideal for kiosks and other applications in public places.
Built from stainless steel,resistant to vandalism,corrosive,rust
Dust-proof and liquid-proof, IP65 compliant
Physical properties
Keys stainless steel keypad, Dot matrix keypad
Carbon-on-gold key switch technology
Rear mounting/bracket mounting
USB or PS2 interface available
Custom layout available,generally English layout
Keys :
keyboard keys can be defined according to customer requirements
Key life: more than 200 million times
Key travel: 0.2mm
Key strength: 3N
Operating temperature: -40 ℃ -65 ℃
Keycaps:
keycap font is black, the function keys have colored icon
etched keycaps graphic, paint by special process
keycap graphic can be customized
Operating system
Operating system: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Windows 7, Windows 8, Windows 9, Windows 10, Linux, Unix, Mac osx
Electrical Data
Power supply voltage: DC 5 V ± 5%
Current rating: 20 mA
Interface: USB or PS2
EMC Emission:EN55022(B)
Environmental adaptability
Operating temprature:-25℃~+70℃
relative humidity:30%~90%RH
Storage temprature:-25℃~+70℃
relative humitity:20%~95%RH(non-condensate)
BARO:60~106Kpa
